The best company that leads IOT and provides trust and value to customers
| ITEM | Specification | |
|---|---|---|
| LTE ROUTER | CPU | Arm 32bit Cortex-A7 CPU, built-in Linux (MDM9X07 or MDM9X28) |
| GPS | A-GPS & S-GPS | |
| Ethernet | 2 Port | |
| USB | 1 Port | |
| MCU | Core | Arm 32bit Cortex-M4 CPU w/h FPU, 170MHz |
| Memory | Flash Memory : 512KB SRAM Memory : 96KB |
|
| CAN | 2 Port (CAN-FD Support) | |
| RS232C | 1 Port | |
| SIM Card | micro uSIM Socket, (eSIM support) | |
| Back Up Battery | 700mA 4.2V Lithium-Ion Pack Battery | |
| Power |
+7V ~ +36V - Reverse Voltage Protection - Over Voltage Protection - Over Current Protection |
|
| Dimension | Size | 89 x 62 x 23mm |
| Material | Plastic | |
